Discontinued product Discontinued product

This product is no longer available. Please see our current Hygiene & Bathing range here.

Request a quote

Please complete the below form to request a quote. Please note, personal data you provide will not be used or stored unless you would like to stay connected. For more information, view our Privacy Policy that can be found at the bottom of this page.

Invacare takes data protection seriously. Please read our privacy policy for information on how we handle your data and what your rights are.
Specifications & Downloads
Technical data
Technical data
Article no. / Item code

Article no. / Item code

1525771

Seat width

Seat width

450 mm

Seat depth

Seat depth

450 mm

Seat height

Seat height

480 mm

Total width

Total width

575 mm

Total depth

Total depth

810 mm

Total height

Total height

945 mm

Width between armrests

Width between armrests

470 mm

Height to armrests

Height to armrests

755 mm

Width between inside armrests

Width between inside armrests

470 mm

Height, ground to lower seat edge: with holder for toilet pan without holder for toilet pan

Height, ground to lower seat edge: with holder for toilet pan without holder for toilet pan

420 mm

Height, floor to cover plate

Height, floor to cover plate

525 mm

Height, footrests to seat

Height, footrests to seat

345 - 460 mm

Width, cut out in seat plate

Width, cut out in seat plate

220 mm

Depth, cut out in seat plate

Depth, cut out in seat plate

260 mm

Depth without footrests

Depth without footrests

545 mm

Footplate depth

Footplate depth

155 mm

Max. User weight

Max. User weight

160 kg

Weight

Weight

14 kg

Wheel diameter / Castors diameter

Wheel diameter / Castors diameter

5" (127 mm)

Frame colour

Frame colour

Black anthracite

User Manual (1)
